Leírás és Paraméterek
| KAMERA | |
|---|---|
| Képérzékelő | 1/2.8” Progressive Scan CMOS |
| Optika | 2.8 mm/ 4 mm/ 6 mm |
| Aperture | 2.8 mm: F1.6 4 mm: F1.6 6 mm: F1.6 |
| Lens Mount | M12 |
| Látószög | 2.8mm: 107.5°/57.2°/128.7°(H/V/D) 4mm: 89.1°/45.1°/106.9°(H/V/D) 6mm: 55.1°/30.2°/64°(H/V/D) |
| Day/Night Mechanism | IR Cut Filter |
| IR Working Distance | 30m |
| Min. szükséges megvilágítás | Color: 0.005 Lux; 0 Lux with IR/White Light |
| Weatherproof Rating | IP67 |
| Digital Noise Reduction | 3D DNR |
| WDR | DWDR |
| HÁLÓZAT | |
|---|---|
| Biztonság | Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication |
| Szabvány | TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS |
| API | ONVIF |
| Simultaneous Live View | 3 Main Streams & 3 Sub-Streams |
| Client | VIGI App, VIGI Security Manager, VIGI NVR, Web |
| ÁLTALÁNOS | |
|---|---|
| Csomagolás tartalma | VIGI Network Camera Quick Start Guide Waterproof Cable Attachments Mounting Accessories |
| Operating Temperature | -30–60 °C |
| Certifications | CE/BSMI/VCCI/ONVIF |
| Méret (Ma x Sz x Mé) | 174 × 78 × 70 mm |
| Material | Plastic |
| General Features | Two Streams, Mirror, Privacy Masks, Password Reset via E-mail, HTTP Listening |
| Power Supply | 12V DC ± 5%, 5.5mm Coaxial Power Plug PoE (802.3af/at, class 0) |
| Power Consumption | 12V DC: Max 5.4W PoE: Class 0 |
| VIDEÓ/KÉP | |
|---|---|
| Videó tömörítés | Main Stream: H.265+/H.265/H.264+/H.264 Sub-Stream: H.265/H.264 |
| Kép frissítés (frame) és felbontás | Main Stream: Frame Rate: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps Resolution: 2304x1296, 2048x1280, 1920x1080, 1280x720 Sub-Stream: Frame Rate: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps Resolution: 704x576, 640x480, 352x288, 320x240 |
| Max. Resolution | 3MP (2304 × 1296) |
| Videótovábbítás | Main Stream Sub-Stream |
| Képbeállítás | Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance Adjustable by Client Software, Rotation(90°/270°) |
| Image Enhancement | BLC/3D DNR/HLC/SmartIR |
| Video Bit Rate | 64 Kbps to 4 Mbps |
| Day/Night Switch | Day/Night/Auto/Schedule |
| SMART FEATURE-SET | |
|---|---|
| Smart Event | Human & Vehicle Classification, Intrusion Detection, Line-Crossing Detection, Human Detection, Vehicle Detection, Region Entering Detection, Region Exiting Detection, Object Abandoned Detection, Object Removal Detection |
| Basic Event | Motion Detection, Camera Tampering Detection, Exception (Illegal Login) |
| Linkage Method | Trigger Notification: ONVIF, HTTPS |
| Region of Interest | 1 Region |
| FIZIKAI KEZELŐFELÜLET | |
|---|---|
| Hálózati csatlakozás | 1 RJ45 10/100M Self-Adaptive Ethernet Port |
| Gomb | - |
| Video Output | - |
| On-board Storage | - |
| Built-in Microphone | Yes |
| Csatlakozók | LAN |
| Felbontás | 1920 x 1080 (FHD1080) 16:9 |
| Gyártó | TP-LINK |
| Kültéri kivitel | Van |
| Színes/FF | Színes |
