| QBT-B |
| LH98QBTBPGCXEN |
| |
|
|
| |
| Specifications |
| |
| Display |
| |
- Diagonal Size: 98"
-
Panel Type: IPS
-
Resolution: 3,840 x 2,160
-
Pixel Pitch (HxV, mm): 562.2(H) x 562.2(V) um
-
Brightness (Typ): 350 nit
-
Contrast Ratio: 1,200:1
-
Viewing Angle (H/V): 178/178
-
Response Time: 8ms
-
Color Gamut: 72%
-
Glass Haze: 25%
-
H-Scanning Frequency: 60Hz
-
Maximum Pixel Frequency: 594MHz
-
V-Scanning Frequency: 135kHZ
-
Dynamic Contrast Ratio: Mega
.
|
| |
| |
| Connectivity |
| |
- HDMI In: 2
-
DP In: Yes
-
DVI In: Yes
-
Version of HDMI: 2
-
Version of DP: 1.2
-
Version of HDCP: 2.2
-
Tuner In: N/A
-
USB: 2
-
Component In: N/A
-
Composite In: N/A
-
RGB In: N/A
-
IR In: Yes
-
HDBaseT In: N/A
-
Audio In: Yes
-
Audio Out: Stereo Mini Jack
-
Video Out: Yes
-
Power Out: N/A
-
RS232 In: Yes
-
RS232 Out: Yes
-
RJ45 In: Yes
-
RJ45 Out: N/A
-
WiFi: Yes
-
3G Dongle: N/A
-
Bluetooth: N/A
.
|
| |
| |
| Power |
| |
- Power Supply: AC100-240V 50/60Hz
-
Power Consumption (Off Mode, W): N/A
-
Power Consumption (On Mode, W): 462 W
-
Power Consumption (Sleep Mode, W): 0.5 W
.
|
| |
| |
| Dimension |
| |
- Set Dimension (WxHxD, mm): 2195.8 x 1250.8 x 96.5 mm
-
Package Dimension (WxHxD, mm): 2369 x 1405 x 350 mm
.
|
| |
| |
| Weight |
| |
- Set Weight: 83 kg
-
Package Weight: 106 kg
.
|
| |
| |
| Operation Conditions |
| |
- Temperature: 0 °C~ 40 °C
-
Humidity: 10 ~ 80%, non-condensing
.
|
| |
| |
| Mechanical Specification |
| |
- VESA Mount (mm): 800 x 400 mm
-
Bezel Width (mm): 17.9
-
Frame Material: Non-Glossy
.
|
| |
| |
| General Feature |
| |
- External Memory Slot: N/A
.
|
| |
| |
| Optional Feature |
| |
- Mount: WMN8200SG
-
Stand: N/A
.
|
| |
| |
| SoC |
| |
- OS Version: Tizen 4.0
-
Flash Memory Size: 8GB
.
|
| |
| |
| Eco |
| |
- Energy Efficiency Class: N/A
.
|
| |
| |
| Certification and Compliance |
| |
- EMC: Class A
-
Safety: 60950-1, 62368-1
.
|
| |
