Leírás és Paraméterek
CPU
Supports AMD Ryzen™ 5000 Series, 5000 G-Series, 4000 G-Series, 3000 Series and 3000 G-Series processors
CHIPSET
AMD A520 Chipset
MEMORY
- 2x DDR4 memory slots, support up to 64GB 1
- Supports DDR4 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200 MHz by JEDEC
- Supports DDR4 2667/ 2800 /2933 /3000 /3066 /3200 /3466 /3600/ 3733 /3866 /4000 /4133 /4266 /4400/ 4600+ MHz by A-XMP OC MODE
- 1DPC 1R max speed 4600 MHz
- 1DPC 2R max speed 3866 MHz
- Dual channel memory architecture
- Supports non-ECC UDIMM memory
- Supports ECC UDIMM memory (non-ECC mode)
- Supports un-buffered memory
- Please refer www.msi.com for more information on compatible memory.
EXPANSION SLOT
- 1x PCIe 3.0 x16 slot (from AMD processor)1
- Supports x16 speed with Ryzen™ 5000, 5000G, 4000G and 3000 processors
- Supports x8 speed with Ryzen™ 3000G processors
- Supports x4 speed with AMD® Athlon™ with Radeon Graphics processors
- 1x PCIe 3.0 x1 slot
- The supported specification depends on installed processor.
ONBOARD GRAPHICS
- 1x HDMI™ 2.1 port, supports a maximum resolution of 4096x2160 @60Hz12
Support HDCP 1.4 & 2.3 - 1x DVI-D port, supports a maximum resolution of 1920x1200@60Hz1
- Maximum shared memory of 16 GB
- Available for the processor with integrated graphics.
- Graphics specifications may vary depending on the CPU installed.
STORAGE
AMD A520 Chipset
- 4x SATA 6Gb/s ports
- 1x M.2 slot (Key M) (from AMD Processor)
- Supports PCIe 3.0 x4 & SATA 6G/s with Ryzen™ 5000, 5000G, 4000G, 3000 and 3000G processors
- Supports SATA 6Gb/s with Athlon™ with Radeon™ Vega Graphics processors
- Supports 2242/ 2260/ 2280 storage devices
RAID
- Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices
- Supports RAID 0 and RAID 1 for M.2 NVMe storage devices
USB
AMD A520 Chipset
- 2x USB 3.2 Gen 1 5Gbps ports are available through the internal USB 3.2 Gen 1 5Gbps connector
- 6x USB 2.0 ports (2 Type-A ports on the back panel, 4 ports through the internal USB 2.0 connectors)
AMD Processor
- 4x USB 3.2 Gen 1 5Gbps Type-A ports on the back panel
AUDIO
Realtek® ALC892/ALC897 Codec
- 7.1-Channel High Definition Audio
LAN
- 1x Realtek® RTL8111H Gigabit LAN controller
| Audio | 7.1 HD |
| Chipset gyártó | AMD |
| D-Sub | Nincs |
| Display Port | Nincs |
| DVI | Van |
| Foglalat típusa | AM4 |
| Form Factor | mATX |
| Grafikus foglalat | PCI-Ex16 3.0 |
| Gyártó | MSI COMPUTER |
| HDMI | Van |
| Kivitel | dobozos |
| LAN1 | 10/100/1000 Mb/s |
| M.2 foglalat | Nincs |
| Max memória | 32 |
| Memória foglalatok száma | 2 |
| Memória órajel | 3200 |
| Memória típus | DDR4 |
| Párhuzamos port | Nincs |
| PCI-E foglalatok száma | 1 |
| PS/2 Port | 1 |
| Quad Channel | Nincs |
| Raid | Igen |
| SATA III | 4 |
| Soros port | Nincs |
| Thunderbolt | Nincs |
| USB 2.0 | 2 |
| USB 3.1 | 4 |
| Wireless | Nincs |
