Leírás és Paraméterek
DISPLAY CHARACTERISTICS
| Design | Edge to edge glass |
| Diagonal | 15.6", 39.5cm |
| Panel | IPS Panel Technology, LED |
| Native resolution | 1920 x 1080 (2.1 megapixel HD) |
| Aspect ratio | 16:9 |
| Panel brightness | 450 cd/m² |
| Brightness | 385 cd/m² with touch |
| Light transmittance | 85% |
| Static contrast | 800:1 with touch |
| Response time (GTG) | 25ms |
| Viewing zone | horizontal/vertical: 170°/170°, right/left: 85°/85°, up/down: 85°/85° |
| Colour support | 16.7mln 8bit |
| Horizontal Sync | 30. - 84.kHz |
| Viewable area W x H | 344.16 x 193.59mm, 13.5 x 7.6" |
| Pixel pitch | 0.17925mm |
| Bezel colour and finish | black, matte |
TOUCH
| Touch technology | projective capacitive |
| Touch points | 10 |
| Touch method | finger, glove (latex), capacitive stylus |
| Touch interface | USB |
INTERFACES / CONNECTORS / CONTROLS
| Digital signal input | HDMI x1 |
| Audio input | Mini jack x1 |
| Audio output | Speakers 2 x 2W |
| USB ports | x2 (2.0) |
FEATURES
| Extra | media player, SD card slot |
| Max. non-stop operating time | 24/7 |
| Glass thickness | 1.8mm |
| Glass hardness | 6H |
| OSD key lock | yes |
GENERAL
| Control buttons | Power/Input select, navigation button (up, down, left, right, play/enter, pause), menu/exit |
| User controls | Photo, music, video, calendar, settings (OSD language, auto play, repeat mode, slideshow time, time, display mode, brightness, contrast, saturation, auto power, restore factory mode) |
MECHANICAL
| Orientation | landscape, portrait, face-up |
| VESA mounting | 100 x 100mm |
ACCESSORIES INCLUDED
| Cables | USB, HDMI |
| Guides | quick start guide, safety guide |
| Other | AC adapter |
POWER MANAGEMENT
| Power supply unit | external |
| Power supply | DC 12 V |
| Power usage | 7W typical, 0.5W stand by, 0.1W off mode |
SUSTAINABILITY
| Regulations | CE, RoHS support, ErP, WEEE, REACH, UKCA |
| Energy efficiency class (Regulation (EU) 2017/1369) | E |
| REACH SVHC | above 0.1%: Lead |
DIMENSIONS / WEIGHT
| Product dimensions W x H x D | 388 x 245 x 159.5mm |
| Weight (without box) | 2.6kg |
| EAN code | 4948570120451 |
| Beépített tápegység | Nincs |
| Fali rögzítés | 100x100mm VESA falitartó-támogatás |
| Fejhallgató kimenet | Van |
| Felbontás | 1920 x 1080 (FHD1080) 16:9 |
| Fényerő | 380 |
| Gyártó | IIYAMA |
| Hangszóró | Van |
| HDMI | Van |
| Képarány | 16:9 |
| Képátló | 15.6 |
| Panel típus | IPS |
| Típus | Touch monitor |
| USB | Van |
| Válaszidő | 25 |
