Leírás és Paraméterek
Radiator Support - Rear120mm
Dust FiltersTop
Materials - ExteriorMesh
Materials - Left Side PanelTempered Glass
Included AccessoriesARGB Fans Hub
Materials - ExteriorSteel
Dust FiltersFront
Warranty2 years
Exterior ColorBlack
3.5" Drive Bays2
Radiator Support - Front360mm
SeriesMasterBox Series
SizeMid Tower
Radiator Support - Top360mm
Dust FiltersBottom
Motherboard SupportSSI CEB
Power Supply SupportATX
Exterior ColorWhite
Materials - ExteriorABS Plastic
Fan Support - Rear1x 120mm
Radiator Support - Top280mm
Radiator Support - Front280mm
Radiator Support - Front240mm
Radiator Support - Top240mm
Materials - ExteriorTempered Glass
Motherboard SupportE-ATX*
Fan Support - Front2x 140mm
Clearance - PSU200mm
Expansion Slots7
Radiator Support - Top140mm
Radiator Support - Front140mm
Motherboard SupportATX
Motherboard SupportMicro ATX
Radiator Support - Top120mm
Radiator Support - Front120mm
Fan Support - Top2x 140mm
Fan Support - Front3x 120mm
2.5" Drive Bays3
Clearance - CPU Cooler165mm/6.49"
Fan Support - Top3x 120mm
Motherboard Support Mini ITX
Motherboard Support(*up to 12" x 10.7" motherboards, may impact cable management feature)
Radiator Support - Top(recommended maximum thickness -55mm)
Clearance - GFX410mm/16.1"
I/O Panel1x 3.5mm Headset Jack (Audio+Mic)
Clearance - PSU(Recommended up to 170mm)
Pre-installed Fans - Front3x CF120 ARGB
I/O Panel1x USB 3.2 Gen 2 Type-C
I/O Panel1x Reset/ARGB button
I/O Panel1x USB 3.2 Gen 1 Type-A
Dimensions (L x W x H)499 x 210 x 498mm (Incl. Protrusions)
Dimensions (L x W x H)430 x 210 x 479mm (Body Size)
Model NumberMB520-KGNN-S00
Model NumberMB520-WGNN-S00
| Gyártó | COOLER MASTER |
