General Specifications
|
Memory Capacity |
Standard |
ADS-1300: 256 MB ADS-1350W/ADS-1800W: 512 MB |
|
Power Source |
DC |
5V, 3A *1 |
|
AC Adapter *2 |
| |
| Touchscreen LCD (Liquid Crystal Display) *3
(ADS-1800W) |
Touchscreen 71.1 mm TFT Colour LCD | |
|
Scanning *6 |
ADS-1300
ADS-1350W
ADS-1800W
| |
|
Ready |
ADS-1300
ADS-1350W
ADS-1800W
| |
|
Sleep |
ADS-1300
ADS-1350W
ADS-1800W
| |
|
Power Down |
ADS-1300
ADS-1350W
ADS-1800W
| |
| Dimensions
|
1: 85 mm 2: 288 mm 3: 205 mm 4: 211 mm 5: 101 mm | |
|
Weights |
ADS-1300: Approximately 1.37 kg ADS-1350W: Approximately 1.37 kg ADS-1800W: Approximately 1.42 kg | |
|
Temperature |
Operating |
5°C to 35°C |
|
Storage |
0°C to 40°C | |
|
Humidity |
Operating |
20% to 80% |
|
Storage |
10% to 90% | |
|
ADF (Automatic Document Feeder) |
Up to 20 sheets (Paper: 80 g/? A4/Letter size) | |
*1
USB Type-C is supported.
*2
The AC Adapter is an optional accessory and is available on the Brother website by searching for part number LK-1001C.
*3
Measured diagonally.
*4
Measured when the machine is connected to your computer.
*5
When the USB port is connected.
*6
When using 2-sided (duplex) colour scanning at resolutions 300 x 300 dpi.
Document Specifications
|
Paper Type |
Plain Paper, Thin Paper, Thick Paper, Thicker Paper, Non Carbon Paper, Receipt, Recycled Paper, Business Card, Plastic Card | |
|
Document Size |
Width |
50.8 mm to 215.9 mm |
|
Length *1 |
70 mm to 355.6 mm | |
|
Carrier Sheet Restrictions |
Width |
Documents narrower than 50.8 mm |
|
Length |
Documents shorter than 70 mm | |
|
Thickness |
Pages thinner than 0.08 mm | |
*1
Up to 5000 mm when using the Long Paper function.
Scanner Specifications
|
Colour/Monochrome |
Yes/Yes | |
|
TWAIN Compliant |
Windows |
Windows 10 / Windows 11 |
|
WIA Compliant |
Windows |
Windows 10 / Windows 11 |
| ICA Compliant
(ADS-1300) |
Mac |
macOS v11.x / macOS 12.x / macOS 13.x |
|
Colour Depth |
Input |
48 bit colour processing |
|
Output |
24 bit colour processing | |
|
Resolution |
Interpolated |
Up to 1200 x 1200 dpi |
|
Optical |
Up to 600 x 600 dpi | |
|
Scanning Width |
Up to 215.9 mm | |
|
Greyscale |
256 levels | |
|
Max. Speed |
For detailed specifications, visit www.brother.com. | |
Direct Scan Feature (Scan to USB) Specifications
|
Compatible Media |
USB flash drive *1 |
|
Interface |
Interface USB 2.0 Hi Speed |
*1
USB Mass Storage standard up to 128 GB
Supported formats: FAT12/FAT16/FAT32/exFAT
Interface Specifications
|
USB |
USB 3.2 Gen1 Use a USB Type-A to USB Type-C Cable *1 or a USB Type-C to USB Type-C Cable that supports USB Super Speed or USB 2.0 High speed and is no more than 2.0 metres long. |
| Wireless LAN
(ADS-1350W/ADS-1800W) |
2.4 GHz band IEEE 802.11b/g/n (Infrastructure Mode) IEEE 802.11g/n (Wi-Fi Direct) (ADS-1800W) IEEE 802.11g/n (Wireless Direct) (ADS-1350W) |
*1
USB Type-A to USB Type-C Cables do not support USB power.
Network Specifications
|
Wireless Network Security |
WEP 64/128 bit, WPA-PSK (TKIP/AES), WPA2-PSK (TKIP/AES), WPA3-SAE (AES) |
|
Setup Support Utility |
WPS |
Supported Protocols and Security Features
|
Protocol (IPv4) |
|
|
Protocol (IPv6) |
|
|
Network Security (Wireless) |
|
| Network Security (Email)
(ADS-1800W) |
SMTP-AUTH, SSL/TLS (SMTP) |
|
Wi-Fi Certification |
|
Computer Requirements Specifications
| Computer Platform & Operating System Version | Supported PC Software Functions | PC Interface | Processor Minimum Speed | Hard Disk Space to Install | ||
| For Drivers | For Applications | |||||
|
Windows Operating System |
Windows 10 Windows 11 |
Scanning |
USB WLAN (Wi-Fi) *1 |
32bit (x86) or 64bit (x64) processor |
70 MB |
Drivers, Installer and Software: 1.4 GB |
|
Mac Operating System |
macOS v11.x macOS v12.x macOS v13.x |
64bit processor |
30 MB |
Drivers and Software: 600 MB | ||
