Leírás és Paraméterek
Intel:
1851, 1700
AMD:
AM5, AM4
PI | NNPI:
374 | 339
TIM:
MX-6 (0.8 g)
Operating Ambient Temperature:
0—40 °C
Weight:
2325 g
LED Connector:
3-Pin A-RGB Connector
All-In-One Connector:
4-Pin PWM Connector
Splitt Connector:
3x 4-Pin PWM Connector
Pump
Pump:
800—2800 rpm (PWM controlled)
Current | Voltage:
0.35 A | 12 V DC
Cold Plate:
Copper, Micro Skived Fins
Tube Length:
450 mm
Tube Diameter:
Outer: 12.4 mm
Inner: 6.0 mm
Radiator
Material:
Aluminium
Dimensions:
458 (L) x 138 (W) x 38 (H) mm
VRM Module
VRM Fan:
400—2500 rpm (PWM controlled)
Current | Voltage:
0.05 A | 12 V DC
LEDs:
12x A-RGB LEDs
Current | Voltage:
0.40 A | 5 V DC
Radiator Fans
Fan:
3x P14 PWM PST A-RGB
Speed:
200—1900 rpm
Air Flow:
69.90 cfm | 117.06 m3/h
Static Pressure:
2.0 mmH2O
Bearing:
Fluid Dynamic Bearing
Current | Voltage:
0.17 A | 12 V DC
Cable Lenght:
40 mm
Connector:
4-Pin PWM Connector
RGB
LEDs:
12x A-RGB LEDs
Current | Voltage:
0.40 V | 5 V DC
Cable Lenght:
40 mm + 80 mm Splitter Cable
Connector:
3-Pin A-RGB Connector + 3-Pin Plug
| Gyártó | ARCTIC |
| Hűtés típusa | Vízhűtés |
