NOCTUA CPU hűtő NH-U14S DX-4677 LGA4677, Barna

Cooler Specification

Socket compatibility

Intel Xeon LGA4677

Height (without fan)

165 mm

Width (without fan)

150 mm

Depth (without fan)

52 mm

Weight (without fan)

797 g

Height (with fan)

165 mm

Width (with fan)

150 mm

Depth (with fan)

111 mm

Weight (with fan)

1136 g

Material

Copper (base and heat-pipes), aluminium (cooling fins), soldered joints & nickel plating

NSPR

179

Max. TDP

see NSPR

Fan compatibility

140x150x25 (with 120mm mounting holes), 140x140x25 (with 120mm mounting holes), 120x120x25

Scope of delivery

• 2x NF-A15 PWM premium fan
• NA-YC1 4-pin PWM y-cable
• NT-H1 high-grade thermal compound (pre-applied)
• SecuFirm2™ mounting kit for LGA4677
• NM-SMT5 Torx® T30 mounting tool

Warranty

6 Years

FAN Specification

Model

2x Noctua NF-A15 HS-PWM

Bearing

SSO2

Max. rotational speed (+/- 10%)

1500 RPM

Min. rotational speed @ 20% PWM (+/-20%)

300 RPM

Max. airflow

140,2 m3/h

Max. acoustical noise

24,6 dB(A)

Input power (max.)

1,56 W

Voltage range

12 V

MTTF

> 150.000 h
