Leírás és Paraméterek
-
Graphics Processing
Radeon™ RX 6400
-
Core Clock
Boost Clock* : up to 2321 MHz
Game Clock* : up to 2039 MHz -
Stream Processors
768
-
Process Technology
6 nm
-
Memory Clock
16000 MHz
-
Memory Size
4 GB
-
Memory Type
GDDR6
-
Memory Bus
64 bit
-
Memory Bandwidth (GB/sec)
128 GB/s
-
Card Bus
PCI-E 4.0
-
Digital max resolution
7680x4320
-
Multi-view
2
-
Card size
L=182 W=69 H=36 mm
-
PCB Form
Low Profile
-
DirectX
12 Ultimate
-
OpenGL
4.6
-
Recommended PSU
350W
-
Power Connectors
N/A
-
Output
DisplayPort 1.4 *1
HDMI 2.1 *1 -
Accessories
1. Quick guide
2. Low Profile Bracket *1 -
Note
* “Boost Clock” is the maximum frequency achievable on the GPU running a bursty workload. Boost clock achievability, frequency, and sustainability will vary based on several factors, including but not limited to: thermal conditions and variation in applications and workloads.
* “Game Clock” is the expected GPU clock when running typical gaming applications, set to typical TGP (Total Graphics Power). Actual individual game clock results may vary.
| Chipset gyártó | AMD |
| Chipset típusa | RX 6400 |
| Csatlakozófelület | PCI-e x16 |
| D-Sub | - |
| DirectX | 12 |
| Displayport | 1 |
| Gyártó | GIGABYTE |
| HDMI | 1 |
| Hűtés típusa | Aktív |
| Kivitel | dobozos |
| Low profile | Nincs |
| Magórajel | 2321 |
| Memória. | 4 |
| Memória órajel | 16000 |
| Memória sávszélesség | 64 Bit |
| Memória típusa | GDDR6 |
| Mini Displayport | - |
| OpenGL | 4.6 |
| SLI/CrossFire támogatás | Van |
| USB Type-C | - |
