| DJI RS 3 Mini |
| |
| |
| In the Box |
| |
- Gimbal x1
-
USB-C Charging Cable (40 cm) x1
-
L-Shaped Multi-Camera Control Cable (USB-C, 30 cm) x1
-
RS Mini Quick-Release Plate x1
-
RS Mini Tripod x1
-
Screw Kit x1
.
|
| |
| |
| Specs |
| |
| Peripheral |
| |
- Accessory Port:
1/4"-20 Mounting Hole
RSS Camera Control Port (USB-C)
NATO Expansion Port
-
Battery:
Model: HB7-2450mAh-7.2
Type: 18650 Li-ion 2S
Capacity: 2450 mAh
Energy: 17.64 Wh
Operating Time: 10 hours [1]
Charging Specification: 5 V/2 A
Charging Time: Approx. 2.5 hours [2]
Suggested Charging Temperature: 5° to 40° C (41° to 104° F)
-
Connections:
Bluetooth 5.1
USB-C Charging Port
-
Ronin App Requirements:
iOS 11.0 or above
Android 7.0 or above
-
Languages Supported by the Touchscreen: English, Simplified Chinese, Traditional Chinese, German, French, Korean, Japanese, Spanish, Portuguese (Brazil), Russian, Thai
.
|
| |
| |
| Working Performance |
| |
- Tested Payload: 0.4-2 kg (0.8-4.4 lbs)
-
Maximum Controlled Rotation Speed:
Pan: 360°/s
Tilt: 360°/s
Roll: 360°/s
-
Mechanical Range:
????Pan Axis: 360° continuous rotation
Roll Axis: -95° to +240°
Tilt Axis: -110° to +210°
.
|
| |
| |
| Mechanical & Electrical Properties |
| |
- Operating Frequency: 2.4000-2.4835 GHz
-
Bluetooth Transmitter Power: <4 dBm
-
Operating Temperature: -10° to 45° C (14° to 113° F)
-
Weight:
Gimbal: 795 g (1.75 lbs) in portrait mode and 850 g (1.8 lbs) in horizontal shooting mode (both including the Quick-Release Plate and excluding the Extended Grip/Tripod)
Extended Grip/Tripod: Approx. 128 g (0.2 lbs)
-
Dimensions:
Folded: 323×195×98 mm (L×W×H, height excludes the Extended Grip/Tripod)
Unfolded: 180×159×296 mm (L×W×H, excluding camera and the Extended Grip/Tripod)
.
|
| |
| |
| Other |
| |
- Footnotes:
1. Measured with the equipment in a level and stationary state and the gimbal balanced. When the gimbal is in motion, the operating time will be reduced.
2. Tested in a 25° C (77° F) environment while using a 10W charger.
.
|
| |
