Leírás és Paraméterek
| Part No | 90NX06R1-M01670 | |||||
| Sales Model Name | B5404CMA-QN1021 | |||||
| EAN Code | ||||||
| UPC Code | ||||||
| WEEE | 1.11 | |||||
| BASE UNIT | VSNX06R1-BU6211 | |||||
| Operating System | Non-preinstalled OS | |||||
| Office | ||||||
| LCD cover-material | Aluminum | |||||
| LCD cover-color | Star Black | |||||
| Top case-material | Aluminum + MgAl | |||||
| Top case-color | Star Black | |||||
| Bottom case-material | Aluminum | |||||
| Bottom case-color | Star Black | |||||
| Military grade | US MIL-STD 810H military-grade standard | |||||
| Panel Size | 14.0-inch | |||||
| Backlit | LED Backlit | |||||
| OLED | ||||||
| Brightness | 500nits | |||||
| Resolution | WQXGA (2560 x 1600) 16:10 | |||||
| Glare | Anti-glare display | |||||
| Color gamut | DCI-P3: 100% | |||||
| View angle(H/V) | 178/178 | |||||
| Response time(Typ/Max) (ms) | 25/30 | |||||
| Refresh rate | 120Hz | |||||
| Contrast (Typ) | 1500:1 | |||||
| Touch Panel | Non-touch screen | |||||
| Screen-to-body ratio | 84 % | |||||
| Pantone | ||||||
| IPS-level | Wide view | |||||
| VESA CERTIFIED Display HDR | ||||||
| Processor | Intel® Core™ Ultra 5 Processor 125H 1.2 GHz (18MB Cache, up to 4.5 GHz, 14 Cores) Intel® AI Boost NPU | |||||
| Neural processor | Intel® AI Boost NPU | |||||
| Chipset | N/A | |||||
| Discrete/Share | Share | |||||
| Integrated GPU | Intel® Graphics | |||||
| VRAM | N/A | |||||
| How to upgrade memory | Upgradable Need to remove bottom/top case | |||||
| Expansion Slot(includes used) | 2x DDR5 SO-DIMM slots 1x M.2 2230 PCIe 4.0x4 1x M.2 2280 PCIe 4.0x4 | |||||
| On board memory | N/A | |||||
| DIMM Memory | 16GB DDR5 SO-DIMM | |||||
| Total System Memory | DDR5 16GB | |||||
| Storage | 512GB M.2 2280 NVMe™ PCIe® 4.0 SSD SSD Housing for storage expansion | |||||
| SSD Cache | N/A | |||||
| Front-facing camera | 1080p FHD camera with IR function to support Windows Hello With privacy shutter | |||||
| Wireless | Wi-Fi 7(802.11be) (Triple band) 2*2 + Bluetooth® 5.4 Wireless Card | |||||
| On board Wireless | ||||||
| WWAN | ||||||
| NumberPad | N/A | |||||
| FingerPrint | FingerPrint | |||||
| Keyboard type | Backlit Chiclet Keyboard | |||||
| I/O ports | 2x USB 3.2 Gen 2 Type-A 2x Thunderbolt™ 4, compliant with USB4, supports display / power delivery 1x HDMI 2.1 TMDS 1x 3.5mm Combo Audio Jack 1x RJ45 Gigabit Ethernet N/A | |||||
| Audio | Dolby Atmos Built-in array microphone | |||||
| Battery | 63WHrs, 3S1P, 3-cell Li-ion | |||||
| AC Adapter | TYPE-C, 65W AC Adapter, Output: 20V DC, 3.25A, 65W, Input: 100~240V AC 50/60Hz universal | |||||
| Dimension (WxHxD) | 31.37 x 22.68 x 1.89 ~ 1.90 cm (12.35" x 8.93" x 0.74" ~ 0.75") | |||||
| Weight (with Battery) | 1.34 kg (2.95 lbs) // 63 WHrs battery | |||||
| Weight (w/ 2nd Battery) | ||||||
|
