Leírás és Paraméterek
| Part No | 90NX0801-M01XT0 |
| Sales Model Name | B1503CVA-S71773 |
| EAN Code | 4711387877050 |
| UPC Code | 197105877054 |
| WEEE | 1.26 |
| BASE UNIT | VSNX0801-BUB121 |
| Operating System | Non-preinstalled OS |
| LCD cover-material | Plastic |
| LCD cover-color | Gentle Grey |
| Top case-material | Plastic |
| Top case-color | Gentle Grey |
| Bottom case-material | Plastic |
| Bottom case-color | Gentle Grey |
| Military grade | US MIL-STD 810H military-grade standard |
| Panel Size | 15.6-inch |
| Backlit | LED Backlit |
| Brightness | 300nits |
| Resolution | FHD (1920 x 1080) 16:9 |
| Glare | Anti-glare display |
| Color gamut | NTSC: 45% |
| View angle(H/V) | 170/170 |
| Response time(Typ/Max) (ms) | 20/25 |
| Refresh rate | 60Hz |
| Contrast (Typ) | 800:1 |
| Touch Panel | Non-touch screen |
| Screen-to-body ratio | 87 % |
| IPS-level | Wide view |
| Processor | Intel® Core™ i5-1335U Processor 1.3GHz (12M Cache, up to 4.6GHz, 10 cores) |
| Chipset | N/A |
| Discrete/Share | Share |
| Integrated GPU | Intel® UHD Graphics |
| VRAM | N/A |
| How to upgrade memory | Upgradable; Need to remove bottom/top case |
| Expansion Slot(includes used) | 2x DDR5 SO-DIMM slots 1x M.2 2230 PCIe 4.0x4 1x M.2 2280 PCIe 4.0x4 |
| DIMM Memory | 8GB DDR5 SO-DIMM |
| Total System Memory | DDR5 8GB |
| Storage | 512GB M.2 2280 NVMe™ PCIe® 4.0 SSD SSD Housing for storage expansion |
| Front-facing camera | 720p HD camera With privacy shutter |
| Wireless | Wi-Fi 6E(802.11ax) (Dual band) 2*2 + Bluetooth® 5.3 Wireless Card |
| NumberPad | N/A |
| FingerPrint | FingerPrint |
| Keyboard type | Backlit Chiclet Keyboard with Num-key |
| I/O ports | 2x USB 3.2 Gen 1 Type-A 2x USB 3.2 Gen 2 Type-C support display / power delivery 1x HDMI 1.4, up to 3840x2160p/30Hz 1x 3.5mm Combo Audio Jack 1x RJ45 Gigabit Ethernet |
| Audio | Audio by Dirac Built-in speaker Built-in array microphone |
| Battery | 42WHrs, 3S1P, 3-cell Li-ion |
| AC Adapter | TYPE-C, 65W AC Adapter, Output: 20V DC, 3.25A, 65W, Input: 100~240V AC 50/60Hz universal |
| Dimension (WxHxD) | 35.95 x 23.22 x 1.99 ~ 1.99 cm (14.15" x 9.14" x 0.78" ~ 0.78") |
| Weight (with Battery) | 1.64 kg (3.62 lbs) // 42 WHrs battery |
| Weight (w/ 2nd Battery) | 1.65 kg (3.64 lbs) // 50 WHrs battery |
| Weight (w/ 3rd Battery) | 1.68 kg (3.70 lbs) // 63 WHrs battery |
| Weight (w/o Battery) | 1.45 kg (3.20 lbs) |
| Security | Fingerprint sensor intergrated with Touchpad Kensington Nano Security Slot™(6x 2.5mm) BIOS Booting User Password Protection BIOS Integrity Measurement Support BIOS Protection Support BIOS Self Recovery BIOS setup user password CSME BIOS Redundancy Assistance Enhanced Password Strength HDD User Password Protection and Security Intel CSME Firmware Resilience Intel® BIOS Guard Intel® Boot Guard Microsoft Secured-core PC Microsoft Security Level 2 Support Absolute Persistence 2.0 (Computrace) Trusted Platform Module (TPM) 2.0 N/A |
| MyASUS feature | System diagnosis Battery health charging Fan Profile Splendid Tru2Life Function key lock WiFi SmartConnect AppDeals Link to MyASUS |
| Built-in Apps | MyASUS |
| Disclaimer for Built-in Apps | Built-in Apps vary from OS SKU. *MyASUS/McAfee don't support in Pure OS/without OS/G sku/Win SE/Windows on ARM/Linux OS (ex. Endless, Kylin, Ubuntu) |
| Reparability Index (for France) | 9.5 |
| Ecolabels & Compliances | Energy star 8.0 FSC Recycled |
| Base Warranty | |
| 4G/LTE | Nincs |
| Akkumulátor | 3 cell (42Wh) |
| Billentyűzet megvilágítás | Van |
| Bluetooth | Van |
| Dedikált dokkoló | Nincs |
| Dokkolhatóság | USB porton |
| Érintőképernyő (Igen/Nem) | Nincs |
| Felbontás | 1920 x 1080 (FHD1080) 16:9 |
| Gyártó | ASUS |
| Háttértár típus | M.2 SSD |
| Kamera felbontás | 1 |
| Képátló | 15.6 |
| Kijelző Típusa | Matt |
| LAN | 10/100/1000 |
| Memória. | 8 |
| Memória típus | DDR4 |
| Operációs rendszer | Nincs |
| Operációs rendszer verzió | DOS |
| Optikai meghajtó | Nincs |
| Processzor gyártó | Intel |
| Processzor modell | 1335U |
| Processzor típus | Core i5 |
| SSD méret | 512 |
| Súly | 1.62 |
| Szín | Szürke |
| Terméksorozat | ExpertBook |
| USB 3.1 | 2 |
| USB portok száma | 4 |
| USB Type-C | 2 |
| Video csatlakozás | HDMI 1.4 |
| Videokártya | Integrált |
| Videokártya fajta | Integrált |
| Videokártya típus | Intel UHD Graphics |
| Wireless (Wifi) | 802.11ax |
